RYLY-010 ABS Vertical eye wash safety station

Ø  Product features:

Ø  Material:SS304

Ø  Vertical eye washer

Ø  Function: Eye and face rinse

Ø  Nominal pressure: 1.0 Mpa

Ø  Work pressure: 0.2-0.4 Mpa

Ø  Test pressure: 2.0 Mpa

Ø  Use ambient temperature: 0-40C

Ø Eye/Face Washing Water Flow:>114l/min

Ø  Eyewash flow: >1./MIN

Ø  Equipped with dual flow control valve (optional device)

Ø  Influent height: 850mm

Ø  Drainage height: 101mm

Ø  Inlet size: 1/2 inch internal thread

Ø  Drainage outlet size: 1-1/4 inch internal thread

Ø  Production Standard: ANSIZ358.1-2014

Ø  Note: The size of the intake can be customized according to the user's

Ø  needs. It is suggested that emergency valves and filters be installed and

Ø  maintained at the intake.
