l Product features:
l Material: Environmental ABS Material
l Use environment: Suitable for strong acid and alkali indoor
l Environment
l Flushing sprinkler: diversion technology, flushing range
l Expanded by 20%
l Function: Spray +Eyewash
l Nominal pressure: 1.0 Mpa
l Work pressure: 0.2-0.4 Mpa
l Test pressure: 2.0 Mpa
l Use ambient temperature: 0-40 C
l Spray water flow:>75.7/min
l Eye/Face Washing Water Flow:>11.4l/in
l Eyewash flow: >1.5/MIN
l Eye wash height: 1020 mm
l Rinse height: 2180 mm
l Inlet size: 1-1/4 inch internal thread
l Drainage outlet size: 1-1/4 inch internal thread
l Production Standard: ANSIZ358.1-2014
l Note: The size of the intake can be customized according to the user's needs. It is suggested that emergency valves and filters be
installed and maintained at the intake.
